High-Power RF Output up to 50W
100% Continuous Full Duty Cycle
Dynamic Mixed Mode — Digital & Analogue
Remote Monitoring & Programming over IP Network
DRR 9000
Repeater & Systems
The Vertel DRR-9000 is a high-power, robust and continuous duty DMR Repeater Station designed for round-the-clock uptime in mission-critical digital radio networks. With RF power output up to 50 Watts, it enables larger coverage, increased capacity, and exceptional voice quality. Available in VHF and UHF frequency bands, the DRR-9000 supports dynamic mixed-mode capability to automatically handle both digital and analogue calls, with full digital functionality including individual call, text messaging, and emergency calls.
Key Features
- Two Simultaneous Voice / Data Calls in Digital Mode
- Individual Call, Group Call & Emergency Call
- 256-bit AES End-to-End Encryption
- Remote Monitoring & Programming over IP Network
- LED Indication for All Modes (Tx / Rx / Standby / Self-Test)
- Automatic Failover — Switches to DC if AC Power Fails
- Desktop / 19-Inch Rack Mountable
- RF Power: 50W (Programmable / Selectable)
- Hum & Noise: >-40 dB
- Adjacent Channel Power: >-70 dB
- Audio Distortion: <3%
- Protocol: ETSI 102 361-1, -2, -3 & -4
- Sensitivity (Analogue): <0.25 µV (12 dB SINAD)
- Sensitivity (Digital): <0.25 µV @ 5% BER
- Adjacent Channel Selectivity: >70 dB
- Image Rejection: >70 dB
- Intermodulation Rejection: >70 dB
Description
Get detailed product information.
Download BrochureWho It’s Built For
Defense Forces
Fire Fighting Forces
Railways
Airports
Standard Accessories
Adaptor
Charger
Handstrap
Earpiece
Optional Accessories
Adaptor
Charger
Handstrap
Earpiece
